OPTICAL MARK READER Serie A. Exams and surveys corrector

Serie A consists of two models, both with automatic document feeder and output tray, the A72S with a reading head and A108D two to read each printed on both sides simultaneously.

USB connection to your computer include our software, in Castilian that will let you read their standardized OMR forms, validate them in real time and generate an output file open in another application usable Excel, Access, SPSS, etc..

Machine with an excellent value for money ideal for small workloads averages that do not require continuous operation.

This kit includes software Evaldara

Main features:


OMR Serie A A72S A108D
Theoretical peak performance of documents / hour
7200
10800
Readhead
1
2
Words can simultaneously read
1
2 (both sides)
Times reads each page
1
1
Internal printer
No
No
Reading Mode
A sensor. Direct readingon one side
Two sensors. In both sides
Use of equipment
Low volume. Printed on one side only.
Low volume. Printed on both sides.
Inbox
550 documents mx.
Paper thickness
70-150 g/qm
Minimum size
130 x 50 mm
Maximum size
300 x 210 mm
Readehead
Estandard 40 columns 1/5´´
Material
Sheet Metal. Included.
Readhead to pencil, pen, marker, etc..
Incluided
Red light or infrared
Red light
ADF
Incluided
Readhead barcode
No
Display
3 LED´s
Printed thickness control
Incluied
Power control and separation of two printed
Incluided
Feed Rollers
Incluided
Classifier
No
Iniciation
Interface (Flash)
Interface
USB and Serie RS232 standard
Adjustment
Automatic or parameters
Maintenance
Achievable by the user in most situations
weight
8 Kg.
Warranty
1 year
Software
